Camera |
|
Image Sensor |
1/3" Progressive Scan CMOS |
Signal System |
PAL/NTSC |
Min. Illumination |
0.01Lux @ (F1.2, AGC ON), 0 Lux with IR 0.014Lux @ (F1.4, AGC ON), 0 Lux with IR |
Shutter time |
1/3 s to 1/10,000 s |
Lens |
2.8-12mm @ F1.4, -Z: motorized lens |
Lens Mount |
φ14 |
Adjustment Range |
Pan:0° - 355°, Tilt: 0° - 75°, Rotation: 0° - 355° |
Day& Night |
IR cut filter with auto switch |
Wide Dynamic Range |
Digital WDR |
Digital noise reduction |
3D DNR |
Compression Standard |
|
Video Compression |
H.264/MJPEG/H.264+ |
H.264 code profile |
Main Profile |
Video bit rate |
256Kbps~16Mbps |
Dual Stream |
Yes |
Image |
|
Max. Image Resolution |
2560 x 1920 |
Frame Rate |
50Hz: 20fps (2560×1920), 25fps (2048x1536), 25fps(1920×1080), 25fps(1280×720) 60Hz: 20fps (2560×1920), 30fps (2048x1536), 30fps(1920×1080), 30fps(1280×720) |
Main Stream |
50Hz: 20fps (2560×1920), 25fps (2048x1536), 25fps(1920×1080), 25fps(1280×720) 60Hz: 20fps (2560×1920), 30fps (2048x1536), 30fps(1920×1080), 30fps(1280×720) |
Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
BLC |
Support |
ROI |
Support |
Network |
|
Network Storage |
NAS (Support NFS,SMB/CIFS), ANR |
Alarm Trigger |
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
Security |
User Authentication, Watermark, IP address filtering, Anonymous access |
System Compatibility |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
Interface |
|
Audio |
1x audio I/O *only for –S models |
Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
Alarm Input |
-S:1 |
Alarm Output |
-S:1 |
Video Output |
1Vp-p Composite Output (75 Ω, BNC) |
On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
Reset Button |
Yes |
General |
|
Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
Power Supply |
12 VDC ± 10%, PoE (802.3af) |
Power Consumption |
Max. 5.5 W |
Impact Protection |
IK10 |
Weather Proof |
IP66 |
IR Range |
Up to 20m |
Dimensions |
95×105×258.6 mm (3.74” × 4.13” × 10.18”) |
Weight |
1200g (2.6lbs) |
