Camera |
|
Image Sensor |
1/2.7’’ Progressive Scan CMOS |
Min. Illumination |
0.01Lux @ (F1.2, AGC ON), 0 Lux with IR |
Shutter time |
1/3 s to 1/100,000 s |
Lens |
2.7-12mm @ F1.4, horizontal field of view: 113° to 33.8° |
Lens Mount |
φ14 |
Adjustment Range |
Pan:0° - 355°, Tilt: 0° - 75°, Rotation: 0° - 355° |
Day& Night |
IR cut filter with auto switch |
Wide Dynamic Range |
Digital WDR |
Digital noise reduction |
3D DNR |
Compression Standard |
|
Video Compression |
H.264/MJPEG |
H.264 code profile |
BaseLine Profile/Main Profile |
Video bit rate |
32Kbps~8Mbps |
Audio Compression |
G.711/G.722.1/G.726/MP2L2 |
Audio bit rate |
64Kbps(G.711)/ 16Kbps(G.722.1)/ 16Kbps(G.726)/ 32-128Kbps(MP2L2) |
Dual Stream |
Yes |
Image |
|
Max. Image Resolution |
1920 x 1080 |
Frame Rate |
50Hz: 25fps (1920 × 1080,1280 × 960,1280 × 720) 60Hz: 30fps (1920 × 1080,1280 × 960,1280 × 720) |
Image Settings |
Saturation, brightness, contrast adjustable through client software or web browser |
BLC |
Yes, zone configurable |
ROI |
Support |
Network |
|
Network Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS) |
Alarm Trigger |
Tampering alarm, Network disconnect , IP address conflict, Storage exception |
Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
Security |
Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
System Compatibility |
ONVIF, PSIA, CGI, ISAPI |
Interface |
|
Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
General |
|
Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
Power Supply |
12 VDC ± 10%, PoE (802.3af) |
Power Consumption |
Max. 5.5 W |
Impact Protection |
IK10 |
Weather Proof |
IP66 |
IR Range |
Approx 20 to 30 meters(65.6-98.4ft) |
Dimensions |
Φ141 × 99.9 mm (5.55” × 3.94”) |
Weight |
800g (1.76 lbs) |
