Camera |
|
Image Sensor |
1/2.8" Progressive Scan CMOS |
Min. Illumination |
0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR |
Shutter time |
1/3 s to 1/10,000 s |
Lens |
2.8 mm, horizontal field of view 105.8° [2.0 mm (126°), 4 mm (83°), optional] |
Lens Mount |
M12 |
Day& Night |
IR cut filter with auto switch |
Wide Dynamic Range |
120 dB |
Digital noise reduction |
3D DNR |
Compression Standard |
|
Video Compression |
H.264/MJPEG/H.264+ |
H.264 code profile |
BaseLine Profile/Main Profile |
Video bit rate |
32Kbps~8Mbps |
Audio Compression |
G.711/G.722.1/G.726/MP2L2 |
Audio bit rate |
G.711/G.722.1/G.726/MP2L2 |
Dual Stream |
Yes |
Image |
|
Max. Image Resolution |
2688 × 1520 |
Frame Rate |
50Hz: 20fps (2688 × 1520), 25fps (1920 × 1080, 1280×720) 60Hz: 20fps (2688 × 1520), 30fps (1920 × 1080, 1280×720) |
Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
Day/Night Switch |
Support auto, scheduled, and triggered by alarm input |
Network |
|
Network Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS) |
Alarm Trigger |
Intrusion detection, Defocus detection, Motion detection, Face detection, line crossing detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
Security |
One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask,watermark, IP address filtering, Anonymous access |
System Compatibility |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
Interface |
|
Audio |
Internal Microphone and Speaker |
Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
Alarm Input |
1 |
Alarm Ouput |
1 |
On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
Reset Button |
Yes |
Wi-Fi Specification (-W) |
|
Wireless Standards |
IEEE802.11b, 802.11g, 802.11n |
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth |
20/40MHz Support |
Modulation Mode |
802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Transmit Output Power |
11b:17±1.5dBm@11Mbps 11g:14±1.5dBm@54Mbps 11n:12.5±1.5dBm |
Receive Sensitivity |
11b:-90dBm@11Mbps(Typical) 11g:-75dBm@54Mpbs(Typical) 11n:-74dBm(Typical) |
Transmission Rate |
11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps |
Wireless Range |
50m(depend on environment) |
Protocols |
802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM |
General |
|
Operating Conditions |
-10°C ~ 40°C (14°F ~ 104°F), Humidity 95% or less (non-condensing) |
Power Supply |
12 VDC ± 10%, PoE (802.3af) |
Power Consumption |
Max. 5W |
IR Range |
10 meters |
Dimensions |
2.8mm, 4mm lens: 72.3 × 91.9 × 131.3mm (2.85” × 3.62” × 5.17”) 2mm lens: 72.3 × 88.6 × 131.3mm (2.85” × 3.49” × 5.17”) |
Weight |
Approx. 400g (0.88lbs) |
