HIKVISION DS-2CD2420F-I(W)

Rp 1.629.000

tidak termasuk pengiriman

• Up to 2.0 megapixel (1920 x 1080 @ 30 fps) high resolution
• Standard video compression with high compression ratio, ROI (region of interest) encoding
• Progressive scan CMOS
• Built-in Micro SD / SDHC / SDXC card slot, up to 128 GB
• IR range approx. 10 meters
• Two way audio
• Built-in microphone and speaker
• Support Wi-Fi, support WPS configuration with one touch (-W)
• Support PIR(Passive Infrared Detection)
• IR cut filter with auto switch
• Support PoE(802.3af)
• 3D digital Noise Reduction
• Support dual stream, and the sub-stream for mobile surveillance
• Integrated mount for easy installation
• Support Backlight Compensation, Digital Wide Dynamic Range, Auto-electronic shutter and so on
• Other functions: heartbeat, mirror, reset button, etc
• Support Intrusion detection and line crossing detection
• Support VCA, which is compatible with NVR for the second time of video searching and analyzing

Qty:

Overview
Contact Us

Jual IP Camera HIKVISION DS-2CD2420F-I(W) dengan harga murah, kompetitif dan terjangkau di JakartaCCTV. IP Kamera HIKVISION seri Cube ini mampu menstreaming dua video dengan resolusi utama hingga 2.0 MP, dan menangkap gambar dengan lensa 4.0 mm yang disertai dengan jangkauan infra merah 10 meter yang membuatnya dapat memantau objek dalam keadaan gelap gulita hingga jarak 10 meter.

Kamera ini juga dilengkapi dengan built-in microphone & speaker untuk interaksi audio dua arah dan teknologi Digital WDR (Wide Dynamic Range) yang mampu meningkatkan kualitas gambar di area yang gelap dengan menyesuaikan gamma value (γ). Selain itu kamera ini juga mensupport penyimpanan on board hingga 128 GB, pemantauan mobile, deteksi gangguan & line crossing (yang dapat memberitahu penggunanya saat terjadi perampokan ataupun gangguan pada area yang dilindungi, atau ketika seseorang melewati/menerobos area tertentu), yang dikombinasikan dengan teknologi VCA (yang mengizinkan kamera untuk menganalisa rekaman live video dan mengadakan peringatan/tindakan pre-emptive) sehingga membuat kamera ini cocok untuk sistem pemantauan indoor.

FITUR & FUNGSI HIKVISION DS-2CD2420F-I(W)

Up to 2.0 megapixel (1920 x 1080 @ 30 fps) high resolution
Standard video compression with high compression ratio, ROI (region of interest) encoding
Progressive scan CMOS
Built-in Micro SD / SDHC / SDXC card slot, up to 128 GB
IR range approx. 10 meters
Two way audio
Built-in microphone and speaker
Support Wi-Fi, support WPS configuration with one touch (-W)
Support PIR(Passive Infrared Detection)
IR cut filter with auto switch
Support PoE(802.3af)
3D digital Noise Reduction
Support dual stream, and the sub-stream for mobile surveillance
Integrated mount for easy installation
Support Backlight Compensation, Digital Wide Dynamic Range, Auto-electronic shutter and so on
Other functions: heartbeat, mirror, reset button, etc
Support Intrusion detection and line crossing detection
Support VCA, which is compatible with NVR for the second time of video searching and analyzing

Hubungi kami sekarang untuk mendapatkan penawaran terbaik dengan harga distributor yang murah untuk IP Cam HIKVISION DS-2CD2420F-I(W) ini yang disertai dengan garansi resmi 2 tahun dari distributor HIKVISION di Indonesia. Kami, JakartaCCTV akan dengan senang hati membimbing dan membantu anda memilih IP Kamera HIKVISION atau paket CCTV lainnya yang paling cocok untuk kebutuhan anda hingga proses pasang & setting nya.

Camera
Image Sensor	1/2.8" Progressive Scan CMOS
Min. Illumination	0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR 0.028Lux @ (F2.0, AGC ON) ,0 Lux with IR
Shutter time	1/3 s to 1/100,000 s
Lens	4mm@ F2.0, Angle of view: 85° (2.8mm, 6mm optional)
Lens Mount	M12
Day& Night	IR cut filter with auto switch
Wide Dynamic Range	Digital WDR
Digital noise reduction	3D DNR
Compression Standard
Video Compression	H.264/MJPEG
H.264 code profile	Main Profile
Video bit rate	32Kbps~8Mbps
Audio Compression	G.711/G.722.1/G.726/MP2L2
Audio bit rate	64Kbps(G.711) /16Kbps(G.722.1)/16Kbps(G.726) /32-128Kbps(MP2L2)
Max. Image Resolution	1920 x 1080
Frame Rate	50Hz: 25fps(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720) 60Hz: 30fps(1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720)
Image Settings	Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC	Yes, zone configurable
ROI	Support
Network
Network Storage	Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS)
Alarm Trigger	Intrusion detection, Defocus detection, Motion detection, Face detection, line crossing detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception
Protocols	TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
Security	One-key reset, flash-prevention, dual streams, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering, Anonymous access
System Compatibility	ONVIF, PSIA, CGI, ISAPI
Interface
Communication Interface	1 RJ45 10M / 100M Ethernet interface
Alarm Input	1
Alarm Output	1
Wi-Fi Specification (-W)
Wireless Standards	IEEE802.11b, 802.11g, 802.11n
Frequency Range	2.4 GHz ~ 2.4835 GHz
Channel Bandwidth	20/40MHz Support
Modulation Mode	802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM
Security	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmit Power	11b: 17±1.5dBm @ 11Mbps 11g: 14±1.5dBm @ 54Mbps 11n: 12.5±1.5dBm
Receive Sensitivity	11b: -90dBm @ 11Mbps (Typical) 11g: -75dBm @ 54Mpbs (Typical) 11n: -74dBm (Typical)
Transmission Rate	11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps
Wireless Range	50m(depend on environment)
Protocols	802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM
General
Operating Conditions	-10°C ~ 40°C (14°F ~ 104°F), Humidity 95% or less (non-condensing)
Power Supply	12 VDC ± 10%, PoE (802.3af)
Power Consumption	MAX. 4.5W
IR Range	10 meters
PIR	Angle: 80° Range: 10m
Dimensions	72.3×89.9×131.3
Weight	400g(0.88lbs)
NOTE	"-W" series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support the 802.1X protocol.
