video Inputs
|
4 CH, BNC |
HD Video Output
|
720p/ 1080p HDCVI |
Analog Video Out
|
NTSC/ PAL |
Video Output
|
1 HDMI, 1 VGA |
Audio Input
|
1 CH , RCA |
Audio Output
|
1 CH , RCA |
Two-way Talk
|
Reuse audio input/ output CH 1 |
Resolution
|
1920×1080, 1280×1024, 1280×720, 1024×768 |
Multi Screen Display
|
1/4 |
Privasi masking
|
4 rectangular zones (each camera) |
OSD Menu
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Video Compression Format
|
H.264 |
Audio Compression
|
G.711 |
Record Rate
|
1080P (1~15fps)/ 720P/ 960H/ D1 (1~25/30fps) & CIF/ QCIF (1~25/30fps), D1 (1~12/15fps) |
Bit rate
|
96~4096Kb/s |
Record Mode
|
Manual, Schedule (Regular (Continuous), MD), Stop |
Record Interval
|
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Trigger Events
|
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
Video Detection
|
Motion Detection, MD Zones: 396 (22×18), Video Loss & Camera Blank |
Synchronous playback
|
1/4 |
Search Mode
|
Time/ Date, MD & Exact search (accurate to second) |
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode
|
USB Device/ Network |
Network interface
|
RJ-45 port (10/ 100M) |
Network Functions
|
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
Max. User Access
|
128 users |
Mobile
|
iPhone, iPad, Android |
Type
|
1 SATA port, up to 6TB |
USB interface
|
2 ports (1 Rear), USB2.0 |
RS485 Port
|
1 port, For PTZ Control |
Power Supply
|
DC12V/4A |
Power Consumption
|
10W (without HDD) |
Working
|
-10°C~+55°C / 10%~90%RH / 86~106kpa |
Dimensions (mm)
|
Mini 1U, 325mm×255mm×55mm |
Weight
|
1.5KG (without HDD) |
