System |
|
Main Processor |
Dual-core embedded processor |
Operating System |
Embedded LINUX |
Video& Audio |
|
IP Camera Input |
16 channel |
Two-way talk |
1 channel input, 1 channel output, RCA |
Display |
|
Interface |
2 HDMI , 1 VGA |
Resolution |
3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768 |
Display Split |
1/4/8/9/16 |
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Recording |
|
Compression |
H.265/H.264/MJPEG |
Resolution |
12Mp, 8Mp, 6Mp, 5Mp, 3Mp, 1080P, 1.3Mp, 720P & etc. |
Record Rate |
192Mbps |
Bit Rate |
1~ 20Mbps |
Record Mode |
Manual, Schedule(Regular(Continuous), MD), Stop |
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Video Detection & Alarm |
|
Trigger Events |
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
Alarm Input |
16 channel |
Relay Output |
6 channel |
Playback & Backup |
|
Sync Playback |
1/4/8/16 |
Search Mode |
Time/Date, MD & Exact search (accurate to second), Smart search |
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode |
USB Device/Network/Internal SATA burner/eSATA Device |
Network |
|
Ethernet |
2 RJ-45 port (10/100/1000Mbps) |
PoE |
N/A |
Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.) |
Max. User Access |
128 users |
Smart Phone |
iPhone, iPad, Android |
Storage |
|
Internal HDD |
8 SATA III ports, up to 48TB |
External HDD |
1 eSATA port |
Auxiliary Interface |
|
USB |
4 ports (2 Rear USB3.0, 2 Front USB2.0) |
RS232 |
1 port, For PC communication&Keyboard |
RS485 |
1 port, For PTZ control |
General |
|
Power Supply |
Single, AC 100~240V, 50/60 Hz |
Power Consumption |
NVR: 18.8W for non-PoE model(without HDD) |
Working Environment |
-10°C~+55°C/10%~90%RH/86~106kpa |
Dimension(W×D×H) |
2U, 440mm×454mm×95mm |
Weight |
6.6KG for non-PoE model(without HDD) |
