System |
|
Main Processor |
Dual-core embedded processor |
Operating System |
Embedded LINUX |
Display |
|
Interface |
1 HDMI, 1 VGA, 1TV |
Resolution |
1920 × 1080 , 1280 × 1024, 1280 × 720 , 1024 × 768 |
Multi-screen Display |
1/4/8/9/16 |
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Video Detection and Alarm |
|
Trigger Events |
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Camera Blank |
Alarm input |
16 Channel, Low Level Effective, Green Terminal Interface |
Relay Output |
4 Channel, NO/NC Programmable, Green Terminal Interface |
Playback and Backup |
|
Playback |
1/4/8/16 |
Search Mode |
Time /Date, MD and Exact Search (accurate to second), Smart search |
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play,Next File, Previous File, Next Camera,Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
Backup Mode |
USB Device/Network/Internal SATA burner/eSATA Device |
Storage |
|
Internal HDD |
4 SATA III Ports, Up to 6 TB capacity for each HDD |
HDD Mode |
Single |
eSATA |
1 eSATA Port |
Auxiliary Interface |
|
USB |
2 USB Ports (1 USB 2.0 , 1 USB 3.0 ) |
RS232 |
1 Port, for PC Communication and Keyboard |
RS485 |
1 Port, for PTZ Control |
Audio and Video |
|
IP Camera Input |
32 Channel |
Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
Recording |
|
Compression |
H.264+/H.264/MJPEG |
Resolution |
5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc. |
Record Rate |
200Mbps |
Bit Rate |
16Kbps ~ 20Mbps Per Channel |
Record Mode |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Camera Blank, Video Loss), Stop |
Record Interval |
1 ~ 120 min (default: 60 min), Pre-record:1 ~ 30 sec, Post-record: 10 ~ 300 sec |
Network |
|
Interface |
1 RJ-45 Port (10/100/1000Mbps) |
Ethernet Port |
1 Independent 1000Mbps Ethernet Port |
PoE |
16 ports (IEEE802.3at/af) |
Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
Max. User Access |
128 users |
Smart Phone |
iPhone, iPad, Android |
Interoperability |
ONVIF 2.4, CGI Conformant |
Electrical |
|
Power Supply |
AC100V ~ 240V, 50 ~ 60 Hz |
Power Consumption |
<40W (Without HDD) |
Environmental |
|
Operating Conditions |
-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
Storage Conditions |
-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH |
Construction |
|
Dimensions |
1.5U, 440mm×419.6mm×76mm (17.3" x 16.5" x 3.0") |
Net Weight |
4.3kg (9.5 lb) (without HDD) |
Gross Weight |
7kg(15.4 lb)(without HDD) |
Certifications |
|
CE |
EN55022, EN55024, EN50130-4, EN60950-1 |
FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
UL |
UL60950-1+CAN/CSA C22.2 No.60950-1 |
