Main Processor
|
High performance embedded microprocessor |
Operating System
|
Embedded LINUX |
Video Input (BNC)
|
4 channel, BNC |
Standard
|
NTSC(525Line, 60f/s), PAL(625Line, 50f/s) |
Video Output
|
1 HDMI, 1 VGA, 1 TV, BNC |
Audio Input
|
4 channel, BNC |
Audio Output
|
1 channel, BNC |
Bidirectional Talk
|
1 channel Input, BNC(200-2800mV, 30KΩ), 1 channel Output, BNC(200-3000mV, 5KΩ) |
Speaker
|
1 BNC |
Interface
|
1 HDMI, 1 VGA, 1 TV, BNC |
LCD Display Mode
|
7-inch color LCD(-VD only) |
Resolution
|
1280×1024, 1280×720, 1024×768, 800×600 |
Display Split
|
1/4 |
Privasi masking
|
4 self-defined four-sided zones for privacy masking for each camera |
OSD Menu
|
ATM/POS information, camera title, time, video loss, camera lock, motion detection, recording |
Video Compression Format
|
H.264 |
Audio Compression Format
|
G.711 |
Recording Resolution
|
960H(960×576/960×480) / D1/4CIF(704×576/704×480) / HD1(352×576/352×480) / 2CIF(704×288/704×240) / CIF(352×288/352×240) / QCIF(176×144/176×120) |
Record Rate
|
960H/D1(1~25/30fps), CIF/QCIF(1~25/30fps) |
Bit rate
|
48~4096Kb/s |
Record Mode
|
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
Record Interval
|
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Trigger Events
|
Recording, PTZ, Tour, Alarm, Email, FTP, Buzzer & Screen tips |
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
Alarm in
|
9 channel |
Relay Output
|
6 channel |
Playback Channel
|
1/4 |
Search & Playback (Search)
|
ATM/POS, Time/Date, Alarm, Motion Detection & Exact search (accurate to second) |
Search & Playback Functions
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom(any size) |
Backup Mode
|
USB Device / Network /eSATA |
Ethernet
|
RJ-45 port (10/100/1000M) |
Network Functions
|
TCP/IP, UDP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Email, Alarm Server |
Max. User Access
|
20 users |
Smart Phone (Platform)
|
iPhone, iPad, Android, Windows Phone |
Internal HDD
|
4 SATA ports |
External HDD
|
1 eSATA port |
USB Port
|
3 ports (2 rear), USB2.0 |
RS232
|
1 port, For PC communication & Keyboard |
RS485 Port
|
1 port, For PTZ control |
Power Supply
|
AC 100~240 V, 50/60 Hz |
Power Consumption (±10%)
|
20W(without HDD) |
Working Temperature/Humidity
|
-10°C ~+55°C / 10~90%RH / 86~106kpa |
Dimensions (mm)
|
200mm×300mm×180mm |
Weight
|
3.5KG-4.5KG(without HDD) |
