Main Processor
|
Embedded processor |
Operating System
|
Embedded LINUX |
Video Input (BNC)
|
16 channel |
Standard
|
NTSC(525Line, 60f/s), PAL(625Line, 50f/s) |
Audio Input
|
4 channel, RCA |
Audio Output Signal
|
1 channel, RCA |
Two-way Talk
|
1 channel Input, 1 channel Output(reuse the audio output channel), BNC |
Interface
|
1 HDMI, 1 VGA, 1 TV, 1 Spot, BNC |
Resolution
|
1920×1080, 1280×1024, 1280×720, 1024×768 |
Display Split
|
1/4/8/9/16 |
Privasi masking
|
4 rectangular zones (each camera) |
OSD Menu
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Video Compression Format
|
H.264 |
Audio Compression Format
|
G.711 |
Recording Resolution
|
960H/D1/4CIF(704×576/704×480) / HD1(352×576/352×480) / 2CIF(704×288/704×240) / CIF(352×288/352×240) / QCIF(176×144/176×120) |
Record Rate
|
960H/D1/HD1/2CIF/CIF(1~25/30fps); QCIF(1-25/30fps)/CIF(1-6/7fps) |
Bit rate
|
48~3072Kb/s |
Record Mode
|
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
Record Interval
|
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Trigger Events
|
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips |
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
Alarm in
|
16 |
Relay Output
|
3 channel |
Synchronous playback
|
1/4/9/16 |
Search & Playback (Search)
|
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
Search & Playback Functions
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode
|
USB Device / Network |
Ethernet
|
RJ-45 port (10/100M/1000M) |
Network Functions
|
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server |
Max. User Access
|
20 users |
Smart Phone (Platform)
|
iPhone, iPad, Android, Windows Phone |
Internal HDD
|
2 SATA ports, up to 8TB |
USB interface
|
2ports (1 Rear), USB2.0 |
RS232
|
1 port, For PC communication & Keyboard |
RS485 Port
|
1 port, For PTZ control |
Power Supply
|
DC12V/ 3.3A |
Power Consumption (±10%)
|
15W(without HDD) |
Working Temperature/Humidity
|
-10 ~+55°C / 10~90%RH / 86~106kpa |
Dimensions (mm)
|
1U, 375mm×285mm×45mm |
Weight
|
2.35KG(without HDD) |
