Brand: CP Plus

CP Plus CP-UAP-SC23C

Rp 8.700.000

tidak termasuk pengiriman

1/4" CMOS
High resolution of 540TVL
Min. Illumination of 0.5Lux(Color) & 0.05Lux(B/W)Powerful 23x optical zoom
Day/Night (ICR), 2D-DNR, Auto iris, Auto focus, AWB, AGC, BLC
Max 300 °/s pan speed, 360° continuous pan rotation and auto flip with no blind spot monitor
Upto 255 Presets, 5 Auto Pattern, 8 Auto Tour, 5 auto scan
Auto recognition of general protocols Pelco-P/D
Auto restore to previous PTZ and lens status after power failure
IP66 all-environments protection, 4000V thunder-proof, auto constant temperature & anti-fog

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/4" CMOS
Pixels	640H) × 480(V)
Resolution	540 TVL
Min. Illumination	0.5 Lux@F1.6
S/N Ratio	more than 50dB
Electronic Shutter	1/50s~1/10,000s
Special Functions	4000V thunder and wave protection
Zoom Optical	23x
Tilt Range	Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
Lens	3.9 ~ 89.7 mm
Pan Range	Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
Number of Presets	255
Preset Speed	Horizontal: 300°/s, Vertical: 180°/s
Surge Protection	yes
Alarm	Input: 2, Output: 1
Video Output	CVBS: 1.0Vp-p / 75Ω
Power Supply	AC 24V/1.5A(±10%)
Power Consumption	15W(Indoor), 27W(Outdoor, heater on)
IP Rating	IP66
Dimensions	Φ222(mm) x 322(mm)
Weight	5.0kg
Operating Temp	-40ºC ~ 60ºC
Certifications	CE, FCC and RoHS
White Balance (AWB)	Auto / Manual
Gain Control (AGC)	Auto / Manual
Back Light Comp.	ON/OFF
Day & Night (ICR)	Yes

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/4" CMOS
Pixels	640H) × 480(V)
Resolution	540 TVL
Min. Illumination	0.5 Lux@F1.6
S/N Ratio	more than 50dB
Electronic Shutter	1/50s~1/10,000s
Special Functions	4000V thunder and wave protection
Zoom Optical	23x
Tilt Range	Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
Lens	3.9 ~ 89.7 mm
Pan Range	Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
Number of Presets	255
Preset Speed	Horizontal: 300°/s, Vertical: 180°/s
Surge Protection	yes
Alarm	Input: 2, Output: 1
Video Output	CVBS: 1.0Vp-p / 75Ω
Power Supply	AC 24V/1.5A(±10%)
Power Consumption	15W(Indoor), 27W(Outdoor, heater on)
IP Rating	IP66
Dimensions	Φ222(mm) x 322(mm)
Weight	5.0kg
Operating Temp	-40ºC ~ 60ºC
Certifications	CE, FCC and RoHS
White Balance (AWB)	Auto / Manual
Gain Control (AGC)	Auto / Manual
Back Light Comp.	ON/OFF
Day & Night (ICR)	Yes
