Imaging Device
|
1/2.8" 2.38M CMOS (IMX136) |
|
Total Pixels
|
1,952(H) x 1,116(V) |
|
Effective Pixels
|
1,944(H) x 1,104(V) |
|
Scanning System
|
Progressive scan |
|
Min.Illumination
|
Color : 0.1Lux (1/30sec, F1.2, 50IRE), 0.0017Lux (2sec, F1.2, 50IRE), 0.03Lux (F1.2, 30IRE) B/W : 0Lux (IR LED on), 0Lux (F1.2, 30IRE, IR LED on) |
|
S/N RATIO
|
>50dB |
|
Video Output
|
CVBS : 1.0 Vpp / 75 Ω composite, 704 x 480(N), 704 x 576(P), for installation, DIP connector type |
|
Focal Lenght (Zoom Ratio)
|
3 ~ 8.5mm (2.8x) motorized varifocal |
|
Max. Aperture Ratio
|
F1.2 |
|
Angular Field of View
|
H : 105.5°(Wide) ~ 37.1°(Tele) / V : 57.5°(Wide) ~ 21.0°(Tele) |
|
Min. Object Distance
|
0.5m (1.64ft) |
|
Focus Control
|
Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus) |
|
Lens / Mount Type
|
DC auto iris / Board-in type |
|
Pan / Tilt / Rotate Range
|
0° ~ 354° / 0° ~ 67° / 0° ~ 355° |
|
IR LED
|
12 units |
|
Viewable Length
|
15m (49.21ft) |
|
Camera Title
|
Off / On (Displayed up to 45 characters) |
|
Day/Night
|
Auto (ICR) / Color / B/W / External / Schedule |
|
Backlight Compensation
|
Off / BLC |
|
Wide Dynamic Range
|
120dB |
|
Contrast Enhancement
|
SSDR (Off / On) |
|
Digital Noise Reduction
|
SSNRIII (2D+3D noise filter) (Off / On) |
|
Digital Image Stabilization
|
Off / On |
|
Defog
|
Off / Auto / Manual |
|
Motion Detection
|
Off / On (4 zones with 4 points polygonal) |
|
Privasi masking
|
Off / On (32 zones with 4 points of polygonal) |
|
Gain Control
|
Off / Low / Middle / High |
|
White Balance
|
ATW / AWC / Manual / Indoor / Outdoor |
|
Electronic Shutter Speed
|
Minimum / Maximum / Anti flicker |
|
Flip / Mirror
|
Off / On |
|
Intelligent Video Analytics
|
Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection |
|
Alarm I/O
|
Input 1ea / Output 1ea |
|
Alarm Triggers
|
Motion detection, Tampering, Audio detection, Face detection, Network disconnection, Video analytics, Alarm input |
|
Alarm Events
|
File upload via FTP and E-mail, Notification via E-mail, Local storage (SD/SDHC/SDXC) or NAS recording at Event (Alarm triggers), External output |
|
Ethernet
|
RJ-45 (10/100BASE-T) |
|
Video Compression Format
|
H.264 (MPEG-4 part 10/AVC), MJPEG |
|
Resolution
|
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
|
Max. Framerate
|
H.264 : Max. 60fps at all resolutions MJPEG : 1280 x 1024, 1280 x 720, 1024 x 768 : Max. 15fps 800 x 600, 640 x 480, 320 x 240 : Max. 30fps |
|
Video Quality Adjustment
|
H.264 : Compression level, Target bitrate level control MJPEG : Quality level control |
|
Bitrate Control Method
|
H.264 : CBR or VBR, MJPEG : VBR |
|
Streaming Capability
|
Multiple streaming (Up to 10 profiles) |
|
Audio Input
|
Selectable (Mic in / Line in / Built-in mic), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
|
Audio Output
|
Line out (3.5mm stereo mini jack) |
|
Audio Compression Format
|
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
|
Audio Communication
|
Bi-directional audio |
|
IP
|
IPv4, IPv6 |
|
Protocol
|
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
|
Security
|
HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication |
|
Streaming Method
|
Unicast / Multicast |
|
Max. User Access
|
15 users at unicast mode |
|
Edge Storage
|
SD/SDHC/SDXC Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded |
|
Application Programming Interface
|
ONVIF profile S, HTTP API (SUNAPI) 2.0, SVNP 1.2 |
|
Webpage Language
|
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish |
|
Web Viewer
|
Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 Supported Browser : Microsoft Internet Explorer (Ver. 11 ~ 8) Mozilla Firefox (Ver. 19 ~9) * Windows only Google Chrome (Ver. 25 ~ 15) * Windows only Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only |
|
Central Management Software
|
SmartViewer |
|
Operating Temperature / Humidity
|
-10°C ~ +50°C (+14°F ~ +122°F) / less than 90% RH |
|
Storage Temperature / Humidity -
|
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
|
Ingress Protection / Vandal Resistance
|
IP66 / IK10 |
|
Input Voltage / Current
|
12V DC, 24V AC, PoE (IEEE802.3af) |
|
Power Consumption (±10%)
|
Max. 9.5W (Heater off), Max. 13.5W (24V AC - Heater on) |
|
Color / Material
|
Ivory / Aluminium |
|
Dimensions (WxH)
|
135.2 x 54.3 x 124.5mm (5.32" x 2.14" x 4.9") |
|
Weight
|
960g (2.12 lb) |
