Image Sensor
|
1/3” Progressive scan CCD |
Lens
|
4.4-132 mm, F1.4-4.6 Horizontal angle of view 62.9°-2.2° Vertical angle of view 37°-1.2° Autofocus |
Day/Night
|
Automatically removable infrared-cut filter |
Min.Illumination
|
Color: 0.2 lux at 30 IRE F1.4 B/W: 0.04 lux at 30 IRE F1.4 |
Shutter Time
|
1/10000 s to 1/4 s |
Pan/ Tilt/ Zoom
|
Pan: 360° endless, 0.05° - 450°/s Tilt: 220°, 0.05°-450°/s 30x optical zoom and 12x digital zoom, total 360x zoom E-flip, 256 preset positions, Tour recording, Guard tour, Control queue, On-screen directional indicator, Set new pan 0°, Adjustable zoom speed |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Baseline and Main Profiles Motion JPEG |
Video Resolution
|
HDTV 720p 1280x720 to 320x180 |
Video Framerate
|
Up to 30/25 fps (60/50 Hz) in all resolutions |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/MBR H.264 |
Image settings
|
Wide Dynamic Range (WDR), manual shutter time, compression, color, brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behavior at low light, rotation: 0°, 180°, text and image overlay, 32 individual 3D privacy masks, image freeze on PTZ, electronic image stabilization, automatic defog |
Security
|
Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, Digest authentication, User access log, Centralized Certificate Management |
Protocol Support
|
IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, NTCIP |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Connection ONVIF Profile S, specification at www.onvif.org |
Analytics
|
Video motion detection, Autotracking, Active Gatekeeper Support for AXIS Camera Application Platform enabling installation of AXIS Cross-line detection and third-party applications, see www.axis.com/acap |
Trigger Events
|
Analytics, Shock detection, Fan, Temperature, Manual trigger, PTZ moving, PTZ preset, Edge storage events Heater |
Event actions
|
File upload: FTP, SFTP, HTTP, HTTPS network share and email Notification: email, HTTP, HTTPS and TCP, Day/night mode, Guard tour, Video recording to edge storage, Pre- and post-alarm video buffering, PTZ preset, Overlay text, Send SNMP trap |
Data streaming
|
Event data |
Built-in installation aids
|
Pixel counter |
Casing
|
IP66-, NEMA 4X- and IK10-rated metal casing (aluminum), polycarbonate (PC) clear dome, sunshield (PC/ASA) |
Memory
|
512 MB RAM, 128 MB Flash Battery backed-up real-time clock |
Power
|
12.0-13.2 V DC, min. 75 W |
Connectors
|
RJ45 10BASE-T/100BASE-TX, IP66-rated multi-connector for DC power, input and output, including 5 m (16 ft) cable |
Edge Storage
|
Support for SD/SDHC/SDXC card Support for recording to dedicated network-attached storage (NAS) For SD card and NAS recommendations see www.axis.com |
Operating Conditions
|
-20 °C to 75 °C (-4 °F to 167 °F) Humidity 10-100% RH (condensing) |
Storage Temperature
|
-40 °C to 65 °C (-40 °F to 149 °F) |
Approvals
|
EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, C-tick AS/NZS CISPR 22 Class A EN 50121-4, IEC 62236-4, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, NEMA 250 Type 4X EN 60950-1, EN 60950-22, IEC/EN 60529 IP66, MIL-STD-810G 500.5 - Low pressure, 501.5 - High temperature, 502.5 - Low temperature, 503.5 - Temperature shock, 505.5 - Solar radiation, 506.5 - Rain, 507.5 - Humidity, 509.5 - Salt fog, 510.5 - Sand and dustb |
Weight
|
5.6 kg (12.4 lb) |
Dimension
|
Ø302 x 330 mm (Ø12 x 13 in) |
Included accessories
|
AXIS T8605 Media Converter Switch, 5 m (16 ft) IP66-rated multi-connector cable Installation Guide, Windows decoder 1-user license |
Optional accessories
|
Power Supply, SFP modules, AXIS T91A Mounting Accessories, Smoked dome cover, AXIS P8221 Network I/O Audio Module AXIS T90 Illuminators, AXIS T8310 Video Surveillance Control Board, Installation Display, Multi-user decoder license pack |
Video Management Software
|
AXIS Camera Companion, AXIS Camera Station, Video management software from Axis’ Application Development Partners available on www.axis.com/techsup/software |
Language
|
German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese |
