Brand: Axis

Axis Q3505-V

Telp untuk Harga

HDTV 1080p at up to 60 fps.
WDR – Forensic Capture.
Seamless transition between WDR and Lightfinder.
Electronic Image Stabilization.
IK10 impact resistance and IP52 dust and water protection.

Lensa

Qty:

Overview
Specifications
Contact Us

AXIS Q3505-V DOME NETWORK CAMERA

Network kamera AXIS Q3505-V, kamera canggih yang di rancang oleh AXIS untuk memenuhi kebutuhan pengawasan yang sesuai dengan kebutuhan pengguna. Selain telah disuguhkan dengan bermacam fitur yang sangat berguna untuk pengguna, kamera AXIS model ini juga telah di desain secara khusus untuk penggunanya, karena instalasi dan pemasangan kamera yang mudah. Untuk menghemat biaya pemasangan, AXIS Q3505-V telah di dukung dengan fitur Power over Ethernet (PoE) yang mampu menyalurkan listrik tanpa menggunakan kabel power melainkan melaui jaringan. AXIS Q3505 merupakan kamera yang sangat tepat untuk mengawasi aktifitas di dalam ruangan.

Jual Network Kamera AXIS Q3505-V harga kompetitif. Kamera pengawas yang memiliki casing yang kuat terhadap air dan debu serta gangguan yang berasal dari lingkungan sekitar kamera seperti guncangan atau getaran. AXIS Q3505-V di dukungan kamera berkualitas HDTV 1080p sampai dengan 60 frame per detik (fps) sehingga mampu memberikan gambar yang lebih halus dan tajam bahkan pada gerakan cepat sekalipun. Kamera ini juga telah memiliki fungsi WDR (Wide Dynamic Range) sehingga memberikan kualitas gambar yang seimbang baik pada kondisi cahaya yang tinggi. AXIS Q3505-V juga mendukung Axis Electronic Image Stabilization (EIS), yang mampu untuk meningkatkan kualitas video. Kamera model ini merupakan kamera dengan kinerja tinggi dan dapat juga memperbesar gambar tanpa mengurangi kualitas gambar.

FITUR AXIS Q3505-V

Resolusi kamera 1920 x 1200 (WUXGA).
Sensor gambar Progressive scan RGB CMOS 1/2.8”.
Di dukung dengan memori 512 MB RAM, 128 MB Flash.
PoE, Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 2, max. 5.5 W.
Instalasi yang fleksibel sehingga sangat mudah untuk dipasang.
Pan/Tilt/Zoom dengan Digital PTZ, Optical zoom, Preset positions 9 mm: 3x optical zoom and 2x digital zoom, 22 mm: 2.4x optical zoom and 2x digital zoom.
Casing terbuat dari Aluminum dan polycarbonate sehingga memberikan daya tahan kuat dengan kondisi di sekitar kamera.

Kami menyediakan paket CCTV murah dan paket DVR murah mulai dari jual IP camera, jual IR camera, jual Analog camera, jual Dome camera, jual Cube camera, jual Box camera serta jual DVR 4 channels, jual DVR 6 channels, jual DVR 8 channels, jual DVR 12 channels, jual DVR 16 channels, jual DVR 32 channels. Jual 16CH DVRmurah di Jakarta hanya di JakartaCCTV. JakartaCCTV terpercaya dan berpengalaman. Pemasangan CCTV yang langsung ditangani oleh teknisi yang berpengalaman. Kamera network AXIS Q3505-V hanya bisa Anda dapatkan hanya di JakartaCCTV dengan harga network cctv murah.

Spesifikasi produk

Image Sensor	Progressive scan RGB CMOS 1/2.8”
Lens	Varifocal, Remote focus and zoom, P-Iris control, IR corrected, Megapixel resolution 9 mm: Horizontal angle of view: 3 - 9 mm, 105° - 35°, F1.3, 22 mm: Horizontal angle of view: 9 - 22 mm, 33° - 16°, F1.6
Day/Night	Automatically removable infrared-cut filter
Min.Illumination	9 mm: HDTV 1080p 25/30 fps with WDR - Forensic Capture and Lightfinder: Color: 0.18 lux, F1.3; B/W: 0.04 lux, F1.3 HDTV 1080p 50/60 fps: Color: 0.36 lux, F1.3; B/W: 0.08 lux, F1.3, 22 mm: HDTV 1080p 25/30 fps with WDR - Forensic Capture: Color: 0.28 lux, F1.6; B/W: 0.06 lux, F1.6 HDTV 1080p 50/60 fps: Color: 0.56 lux, F1.6; B/W: 0.11 lux, F1.6
Shutter Time	1/142850 s to 2 s
Angle Adjustment	Pan 360°, Tilt -5° to 90° (0° = Parallel to camera mount/bottom), Rotation ±95°
Video Compression	H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High profiles Motion JPEG
Video Resolution	1920x1200 (WUXGA) to 160x90
Video Framerate	HDTV 1080p (1920x1080) with WDR: 25/30 fps with power line frequency 50/60 Hz HDTV 1080p (1920x1080) without WDR: 50/60 fps with power line frequency 50/60 Hz WUXGA (1920x1200) without WDR: 25/30 fps with power line frequency 50/60 Hz
Video Streaming	Multiple, individually configurable streams in H.264 and Motion JPEG, Controllable frame rate and bandwidth, VBR/MBR H.264
Image settings	Compression, Color, Brightness, Sharpness, Contrast, White balance, Exposure control, Exposure zones, Backlight compensation, Fine tuning of behavior at different light levels WDR - Forensic Capture: Up to 120 dB depending on scene Electronic Image Stabilization, Barrel distortion correction, Rotation: 0°, 90°, 180°, 270°, auto, including Corridor Format Text and image overlay, Privacy masks, Mirroring of images
Pan/ Tilt/ Zoom	Digital PTZ, Optical zoom, Preset positions 9 mm: 3x optical zoom and 2x digital zoom, 22 mm: 2.4x optical zoom and 2x digital zoom
Audio streaming	Two-way
Audio Compression	AAC LC 8/16/32 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8kHz, Configurable bitrate
Audio Input / Output	External balanced/unbalanced microphone input or line input, Line output
Security	Password protection, IP address filtering, IEEE 802.1X network access control a , HTTPSa encryption, Digest authentication, User access log
Protocol Support	IPv4/v6, HTTP, HTTPS, SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection ONVIF Profile S; specification at www.onvif.org
Intelligent Video	Video motion detection, Active tampering alarm, Audio detection, Gatekeeper, AXIS Camera Application Platform (ACAP) enabling installation of additional applications
Trigger Events	Intelligent video, External input, Edge storage events, Shock detection
Event actions	File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP External output activation, Pre- and post-alarm video buffering, Video and audio recording to edge storage, Play audio clip, Zoom preset, Overlay text, Send SNMP trap
Built-in installation aids	Remote zoom, Remote focus, Pixel counter, Leveling assistant, Auto rotation
Casing	IP52-rated, IK10 impact-resistant casing with polycarbonate dome, aluminum base and dehumidifying membrane
Memory	512 MB RAM, 128 MB Flash
Power	Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 2, max. 5.5 W
Connectors	RJ45 10BASE-T/100BASE-TX PoE, Terminal block for two configurable inputs/outputs (12 V DC output, max. load 50 mA), 3.5 mm mic/line in, 3.5 mm line out
Edge Storage	microSD/microSDHC/microSDXC slot supporting memory card up to 64 GB (card not included). Support for recording to dedicated network-attached storage (NAS)
Operating Conditions	-10 °C to 50 °C (14 °F to 122 °F) Humidity 10 - 85% RH (non-condensing)
Approvals	IEC/EN/UL 60950-1, EN 55022 Class B, EN 55024, IEC/EN 61000-6-1, IEC/EN 61000-6-2, FCC Part 15, Subpart B, Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B, KCC KN22 Class B, KN24, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-60, IEC 60068-2-78, EN 50121-4 , IEC 62236-4, IEC 60068-2-52, IEC/EN 60529 IP52, IEC/EN 62262 IK10
Weight	1.2 kg (2.6 lb)
Included accessories	Installation Guide, Installation and Management Software CD, Windows decoder 1-user license, Mounting bracket, Drill hole template, Cable gaskets, Resistorx T20 L-key, I/O connector
Video Management Software	AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software

Namamu *

Email Anda *

Pertanyaan *

AXIS Q3505-V DOME NETWORK CAMERA

FITUR AXIS Q3505-V

Resolusi kamera 1920 x 1200 (WUXGA).
Sensor gambar Progressive scan RGB CMOS 1/2.8”.
Di dukung dengan memori 512 MB RAM, 128 MB Flash.
PoE, Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 2, max. 5.5 W.
Instalasi yang fleksibel sehingga sangat mudah untuk dipasang.
Pan/Tilt/Zoom dengan Digital PTZ, Optical zoom, Preset positions 9 mm: 3x optical zoom and 2x digital zoom, 22 mm: 2.4x optical zoom and 2x digital zoom.
Casing terbuat dari Aluminum dan polycarbonate sehingga memberikan daya tahan kuat dengan kondisi di sekitar kamera.

Spesifikasi produk

Image Sensor	Progressive scan RGB CMOS 1/2.8”
Lens	Varifocal, Remote focus and zoom, P-Iris control, IR corrected, Megapixel resolution 9 mm: Horizontal angle of view: 3 - 9 mm, 105° - 35°, F1.3, 22 mm: Horizontal angle of view: 9 - 22 mm, 33° - 16°, F1.6
Day/Night	Automatically removable infrared-cut filter
Min.Illumination	9 mm: HDTV 1080p 25/30 fps with WDR - Forensic Capture and Lightfinder: Color: 0.18 lux, F1.3; B/W: 0.04 lux, F1.3 HDTV 1080p 50/60 fps: Color: 0.36 lux, F1.3; B/W: 0.08 lux, F1.3, 22 mm: HDTV 1080p 25/30 fps with WDR - Forensic Capture: Color: 0.28 lux, F1.6; B/W: 0.06 lux, F1.6 HDTV 1080p 50/60 fps: Color: 0.56 lux, F1.6; B/W: 0.11 lux, F1.6
Shutter Time	1/142850 s to 2 s
Angle Adjustment	Pan 360°, Tilt -5° to 90° (0° = Parallel to camera mount/bottom), Rotation ±95°
Video Compression	H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High profiles Motion JPEG
Video Resolution	1920x1200 (WUXGA) to 160x90
Video Framerate	HDTV 1080p (1920x1080) with WDR: 25/30 fps with power line frequency 50/60 Hz HDTV 1080p (1920x1080) without WDR: 50/60 fps with power line frequency 50/60 Hz WUXGA (1920x1200) without WDR: 25/30 fps with power line frequency 50/60 Hz
Video Streaming	Multiple, individually configurable streams in H.264 and Motion JPEG, Controllable frame rate and bandwidth, VBR/MBR H.264
Image settings	Compression, Color, Brightness, Sharpness, Contrast, White balance, Exposure control, Exposure zones, Backlight compensation, Fine tuning of behavior at different light levels WDR - Forensic Capture: Up to 120 dB depending on scene Electronic Image Stabilization, Barrel distortion correction, Rotation: 0°, 90°, 180°, 270°, auto, including Corridor Format Text and image overlay, Privacy masks, Mirroring of images
Pan/ Tilt/ Zoom	Digital PTZ, Optical zoom, Preset positions 9 mm: 3x optical zoom and 2x digital zoom, 22 mm: 2.4x optical zoom and 2x digital zoom
Audio streaming	Two-way
Audio Compression	AAC LC 8/16/32 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8kHz, Configurable bitrate
Audio Input / Output	External balanced/unbalanced microphone input or line input, Line output
Security	Password protection, IP address filtering, IEEE 802.1X network access control a , HTTPSa encryption, Digest authentication, User access log
Protocol Support	IPv4/v6, HTTP, HTTPS, SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection ONVIF Profile S; specification at www.onvif.org
Intelligent Video	Video motion detection, Active tampering alarm, Audio detection, Gatekeeper, AXIS Camera Application Platform (ACAP) enabling installation of additional applications
Trigger Events	Intelligent video, External input, Edge storage events, Shock detection
Event actions	File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP External output activation, Pre- and post-alarm video buffering, Video and audio recording to edge storage, Play audio clip, Zoom preset, Overlay text, Send SNMP trap
Built-in installation aids	Remote zoom, Remote focus, Pixel counter, Leveling assistant, Auto rotation
Casing	IP52-rated, IK10 impact-resistant casing with polycarbonate dome, aluminum base and dehumidifying membrane
Memory	512 MB RAM, 128 MB Flash
Power	Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 2, max. 5.5 W
Connectors	RJ45 10BASE-T/100BASE-TX PoE, Terminal block for two configurable inputs/outputs (12 V DC output, max. load 50 mA), 3.5 mm mic/line in, 3.5 mm line out
Edge Storage	microSD/microSDHC/microSDXC slot supporting memory card up to 64 GB (card not included). Support for recording to dedicated network-attached storage (NAS)
Operating Conditions	-10 °C to 50 °C (14 °F to 122 °F) Humidity 10 - 85% RH (non-condensing)
Approvals	IEC/EN/UL 60950-1, EN 55022 Class B, EN 55024, IEC/EN 61000-6-1, IEC/EN 61000-6-2, FCC Part 15, Subpart B, Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B, KCC KN22 Class B, KN24, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-60, IEC 60068-2-78, EN 50121-4 , IEC 62236-4, IEC 60068-2-52, IEC/EN 60529 IP52, IEC/EN 62262 IK10
Weight	1.2 kg (2.6 lb)
Included accessories	Installation Guide, Installation and Management Software CD, Windows decoder 1-user license, Mounting bracket, Drill hole template, Cable gaskets, Resistorx T20 L-key, I/O connector
Video Management Software	AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software
