Brand: Axis

Axis Q1932-E

VGA thermal imaging.
Bullet-style design.
Intelligent video.
Power over Ethernet.
Multiple lens options.
Shock detection.

Lensa

Qty:

Overview
Specifications
Contact Us

AXIS Q1932-E THERMAL NETWORK CAMERA

Dengan kecanggihan teknologi yang ditawarkan oleh kamera pengawas dari brand AXIS ini, sehingga sudah banyak pengguna dari berbagai kalangan yang puas dengan hasil kerja Thermal Network Camera AXIS Q1932-E. Kamera network AXIS Q1932-E merupakan kamera yang dapat mendeteksi suhu panas dari benda yang berada pada sekitar area yang terpantau oleh CCTV AXIS Q1932-E, sehingga kamera ini mampu mengawasi lebih baik daripada CCTV biasa lainnya. Kamera yang mampu melihat apa yang tidak terlihat oleh kamera biasa. Kamera ini memiliki resolusi 640 x 480 namun dapat ditingkatkan hingga 800 x 600 (SVGA) sehingga dapat memberikan gambar yang berkualitas dan jelas.

AXIS Q1932-E sangat cocok pada ruangan yang gelap dan minim cahaya. Kamera ini memiliki tingkat sensitifitas NETD < 70 mK. Q1932-E dapat digunakan untuk pengawasan di luar ruangan seperti area yang memerlukan pengawasan secara khusus dan ketat seperti pagar area khusus, lapangan parker atau halaman luar rumah. Kamera AXIS Q1932-E ialah kamera yang sangat cerdas yang memiliki teknologi yang modern sehingga sangat membantu untuk mengawasi berbagai kejadian dan mengurangi tindak kriminal yang marak terjadi. JakartaCCTV menyediakan berbagai CCTV dengan kualitas terbaik, karena JakartaCCTV berpengalaman dan terpercaya.

FITUR AXIS Q1932-E

Video resolusi 640 x 480 namun dapat ditingkatkan hingga 800 x 600 (SVGA).
Video streaming H.264, Motion JPEG, VBR/CBR H.264.
Mampu bertahandan beroperasi dengan baik pada suhu -40 °C to 60 °C (-40 °F to 140 °F), dengan kelembaban 10-100% RH (condensing).
Konektor RJ45 10BASE-T/100BASE-TX.
Memori: 256 MB RAM, 128 MB Flash.
Power over Ethernet IEEE 802.3af Type 1 Class 3 max. 10 W 8-28 V DC, max. 11 W or 20-24 V AC 50-60 Hz, max. 15 VA.
Berat CCTV 2200 g (4.9 lb).
Thermal camera, microSD/microSDHC/microSDXCmemory card slot.

Kami menyediakan Network Camera AXIS Q1932-E murah dan paket DVR murah mulai dari jual IP camera, jual IR camera, jual Analog camera, jual Dome camera, jual Cube camera, jual Box camera serta jual DVR 4 channels, jual DVR 6 channels, jual DVR 8 channels, jual DVR 12 channels, jual DVR 16 channels, jual DVR 32 channels. Kamera network AXIS Q1932-E hanya bisa Anda dapatkan hanya di JakartaCCTV dengan harga network cctv murah. Jual 16CH DVRmurah di Jakarta hanya di JakartaCCTV. JakartaCCTV terpercaya dan berpengalaman. Pemasangan CCTV yang langsung ditangani oleh teknisi yang berpengalaman.

Spesifikasi produk

Image Sensor	Uncooled Micro bolometer 640x480, pixel pitch: 17µm
Lens	10 mm: 57° viewa , F1.2 19 mm: 32° viewa , F1.0 35 mm: 18° viewa , F1.2 60 mm: 10° viewa , F1.25
Sensitivity	NETD < 70 mK
Video Compression	H.264 (MPEG-4 Part 10/AVC), H.264 Main and Baseline Profile Motion JPEG
Video Resolution	Sensor is 640x480. Image can be scaled up to 800x600 (SVGA)
Frame Rate	Up to 30 fps within EU, Norway, Switzerland, Canada, USA, Japan, Australia, New Zealand Up to 8.3 fps in other countriesb
Video Streaming	At least three H.264 and Motion JPEG streams using the same palette, simultaneous and individually configured in max. resolution at 30 fps Controllable frame rate and bandwidth, VBR/CBR H.264
Image settings	Axis' Corridor Format
Audio streaming	Two-way, full duplex
Audio Compression	AAC LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz Configurable bit rate
Audio Input / Output	External microphone or line input, line output
Security	Password protection, IP address filtering, HTTPSc encryption, IEEE 802.1Xc network access control, Digest authentication, User access log
Protocol Support	IPv4/v6, HTTP, HTTPSc , SSL/TLSc , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection ONVIF Profile S; specification at www.onvif.org
Intelligent Video	Audio detection
Trigger Events	Audio, Intelligent video, Temperature, External input, Time scheduled, Shock detection, Edge storage events
Event actions	File upload: FTP, HTTP, network share and email, Notification: email, HTTP and TCP External output activation Pre- and post-alarm video buffering Video recording to edge storage, Audio recording to edge storage
Data streaming	Event data
Casing	IP66-rated metal casing (Aluminium) with integrated dehumidifying membrane and a germanium window Color: White NCS S 1002-B
Memory	256 MB RAM, 128 MB Flash
Power	Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3, max. 10 W 8-28 V DC, max. 11 W or 20-24 V AC 50-60 Hz, max. 15 VA, power supply not included
Connectors	RJ45 10BASE-T/100BASE-TX PoE, terminal block for power, Eight circuit PCB header for two configurable inputs/outputs and audio
Edge Storage	microSD/microSDHC/microSDXC slot supporting memory card up to 64 GB (card not included) Support for recording to dedicated network-attached storage (NAS)
Operating Conditions	-40 °C to 60 °C (-40 °F to 140 °F) Humidity 10-100% RH (condensing)
Approvals	EN 55022 Class A, EN 50121-4, EN 55024, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, C-tick AS/NZS CISPR22 Class A, KCC KN22 Class A, KN24, IEC/EN/UL 60950-1, IEC/EN/UL 60950-22, EN 50581, IEC 60529 IP66, NEMA 250 Type 4X, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6 Class 4M4, IEC 60068-2-27, IEC 60068-2-52, IEC 60721-3-4 Class 4K3
Weight	2200 g (4.9 lb)
Included accessories	Wall and ceiling mount bracket, Pipe converter for US, RJ45 network cable 5 m (16 ft)
Video Management Software	AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software

Namamu *

Email Anda *

Pertanyaan *

AXIS Q1932-E THERMAL NETWORK CAMERA

FITUR AXIS Q1932-E

Video resolusi 640 x 480 namun dapat ditingkatkan hingga 800 x 600 (SVGA).
Video streaming H.264, Motion JPEG, VBR/CBR H.264.
Mampu bertahandan beroperasi dengan baik pada suhu -40 °C to 60 °C (-40 °F to 140 °F), dengan kelembaban 10-100% RH (condensing).
Konektor RJ45 10BASE-T/100BASE-TX.
Memori: 256 MB RAM, 128 MB Flash.
Power over Ethernet IEEE 802.3af Type 1 Class 3 max. 10 W 8-28 V DC, max. 11 W or 20-24 V AC 50-60 Hz, max. 15 VA.
Berat CCTV 2200 g (4.9 lb).
Thermal camera, microSD/microSDHC/microSDXCmemory card slot.

Spesifikasi produk

Image Sensor	Uncooled Micro bolometer 640x480, pixel pitch: 17µm
Lens	10 mm: 57° viewa , F1.2 19 mm: 32° viewa , F1.0 35 mm: 18° viewa , F1.2 60 mm: 10° viewa , F1.25
Sensitivity	NETD < 70 mK
Video Compression	H.264 (MPEG-4 Part 10/AVC), H.264 Main and Baseline Profile Motion JPEG
Video Resolution	Sensor is 640x480. Image can be scaled up to 800x600 (SVGA)
Frame Rate	Up to 30 fps within EU, Norway, Switzerland, Canada, USA, Japan, Australia, New Zealand Up to 8.3 fps in other countriesb
Video Streaming	At least three H.264 and Motion JPEG streams using the same palette, simultaneous and individually configured in max. resolution at 30 fps Controllable frame rate and bandwidth, VBR/CBR H.264
Image settings	Axis' Corridor Format
Audio streaming	Two-way, full duplex
Audio Compression	AAC LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz Configurable bit rate
Audio Input / Output	External microphone or line input, line output
Security	Password protection, IP address filtering, HTTPSc encryption, IEEE 802.1Xc network access control, Digest authentication, User access log
Protocol Support	IPv4/v6, HTTP, HTTPSc , SSL/TLSc , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection ONVIF Profile S; specification at www.onvif.org
Intelligent Video	Audio detection
Trigger Events	Audio, Intelligent video, Temperature, External input, Time scheduled, Shock detection, Edge storage events
Event actions	File upload: FTP, HTTP, network share and email, Notification: email, HTTP and TCP External output activation Pre- and post-alarm video buffering Video recording to edge storage, Audio recording to edge storage
Data streaming	Event data
Casing	IP66-rated metal casing (Aluminium) with integrated dehumidifying membrane and a germanium window Color: White NCS S 1002-B
Memory	256 MB RAM, 128 MB Flash
Power	Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3, max. 10 W 8-28 V DC, max. 11 W or 20-24 V AC 50-60 Hz, max. 15 VA, power supply not included
Connectors	RJ45 10BASE-T/100BASE-TX PoE, terminal block for power, Eight circuit PCB header for two configurable inputs/outputs and audio
Edge Storage	microSD/microSDHC/microSDXC slot supporting memory card up to 64 GB (card not included) Support for recording to dedicated network-attached storage (NAS)
Operating Conditions	-40 °C to 60 °C (-40 °F to 140 °F) Humidity 10-100% RH (condensing)
Approvals	EN 55022 Class A, EN 50121-4, EN 55024, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, C-tick AS/NZS CISPR22 Class A, KCC KN22 Class A, KN24, IEC/EN/UL 60950-1, IEC/EN/UL 60950-22, EN 50581, IEC 60529 IP66, NEMA 250 Type 4X, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6 Class 4M4, IEC 60068-2-27, IEC 60068-2-52, IEC 60721-3-4 Class 4K3
Weight	2200 g (4.9 lb)
Included accessories	Wall and ceiling mount bracket, Pipe converter for US, RJ45 network cable 5 m (16 ft)
Video Management Software	AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software
