| VIDEO |
|
| Imaging Device |
1/2.8" 2.38M CMOS |
| Total / Effective Pixels |
1,952(H) x 1,116(V), 2.18M pixels / 1,944(H) x 1,104(V), 2.14M pixels |
| Scanning System |
Progressive |
| Min. Illumination |
Color : 0.3Lux (1/30sec, F1.6, 50IRE, AGC high) , 0.005Lux (2sec, F1.6, 50IRE, AGC high)
B/W : 0.03Lux (1/30sec, F1.6, 50IRE, AGC high), 0.0005Lux (2sec, F1.6, 50IRE, AGC high)
Color : 0.15Lux (1/30sec, F1.6, 30IRE), 0.0025Lux (2sec, F1.6, 30IRE)
B/W : 0.015Lux (1/30sec, F1.6, 30IRE), 0.00025Lux (2sec, F1.6, 30IRE) |
| S / N Ratio |
50dB |
| Video Output |
CVBS : 1.0 Vpp / 75Ω composite, 720 x 576, for installation |
| LENS |
|
| Focal Length (Zoom Ratio) |
4.44 ~ 142.6mm (Optical 32x) |
| Max. Aperture Ratio |
F1.6(Wide) / F3.63(Tele) |
| Angular Field of View |
H : 62.8°(Wide) ~ 3.14°(Tele) / V : 36.8°(Wide) ~ 1.76°(Tele) |
| Min. Object Distance |
Wide : 1.5m (4.92ft), Tele : 1.9m (6.23ft) |
| Focus Control |
Auto / Manual / One push |
| Lens / Mount Type |
DC auto iris / Board-in type |
| Pan / Tilt / Rotate |
|
| Pan / Tilt Range |
360° Endless / 210° (-15° ~195° ) |
| Pan / Tilt Speed |
Preset : 500°/sec, Manual : 0.024°/sec ~ 120°/sec |
| Sequence |
Preset (255ea), Swing, Group (6ea), Trace, Tour (1ea), Auto run, Schedule |
| Preset Accuracy |
±0.2° |
| Azimuth |
Yes (E / W / S / N / NE / NW / SE / SW) |
| OPERATIONAL |
|
| Camera Title |
Off / On (Displayed up to 45 characters) |
| Day & Night |
Auto (ICR) / Color / B/W |
| Backlight Compensation |
Off / BLC |
| Wide Dynamic Range |
100dB |
| Contrast Enhancement |
SSDR (Samsung Super Dynamic Range) (Off / On) |
| Digital Noise Reduction |
SSNRIII (2D+3D noise filter) (Off / On) |
| Digital Image Stabilization |
Off / On |
| Defog |
Off / Auto / Manual |
| Motion Detection |
Off / On (4ea rectangular zones) |
| Privacy Masking |
Off / On (32 zones of rectangle zone) with zoom threshold mosaic option |
| Gain Control |
Off / Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor / Mercury |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| Digital Zoom |
12x |
| Flip / Mirror |
Off / On |
| Intelligent Video Analytics |
Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection |
| Alarm I/O |
Input 4ea / Output 2ea (Relay) |
| Remote Control Interface |
RS-485 |
| RS-485 Protocol |
Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, Bosch, GE |
| Alarm Triggers |
Motion detection, Tampering, Audio detection, Face detection,
Video analytics, Alarm input, Network disconnection |
| Alarm Events |
File upload via FTP and E-mail, Notification via E-mail, TCP and HTTP, Local storage (SD/SDHC/SDXC) or NAS recording at network disconnected & event (Alarm triggers), External output |
| NETWORK |
|
| Ethernet |
RJ-45 (10/100BASE-T ) |
| Video Compression Format |
H.264 (MPEG-4 part 10 / AVC), MJPEG |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 720 x 576, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
| Max. Framerate |
H.264 : Max. 30fps at all resolutions
MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps
800 x 600, 800 x 450, 720 x 576, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max. 30fps |
| Smart Codec |
Yes |
| Video Quality Adjustment |
H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control |
| Bitrate Control Method |
H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability |
Multiple streaming (Up to 10 profiles) |
| Audio In |
Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
| Audio Out |
Line out (3.5mm mono jack), Max output level : 1 Vrms |
| Audio Compression Format |
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz,
G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
| Audio Communication |
Bi-directional audio |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Security |
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
10 users at unicast mode |
| Edge Storage |
SD/SDHC/SDXC slot for supporting memory card
Motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded
NAS (Network Attached Storage) |
| Application Programming Interface |
ONVIF profile S, SUNAPI (HTTP API), SVNP 1.2 |
| Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Finnish, Norwegian |
| Web Viewer |
Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7
Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 19),
Google Chrome (Ver. 15 ~ 32), Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7)
* Mac OS X only |
| Central Management Software |
SmartViewer, SSM |
| ENVIRONMENTAL |
|
| operating Temperature / Humidity |
24V AC : -50°C ~ +55°C (-58°F ~ +131°F) /
Less than ~ 90% RH
PoE+ : -30°C ~ +55°C (-22°F ~ +131°F) /
Less than 90% RH |
| Storage Temperature / Humidity |
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| Ingress Protection |
IP66 |
| Vandal Resistance |
IK10 |
| ELECTRICAL |
|
| Input Voltage / Current |
24V AC ±10%, PoE+ (IEEE802.3af, Class4) |
| Power Consumption |
24V AC : Max. 65W (24V AC heater on & PoE heater on)
PoE+ : Max. 25W (24V AC heater off / PoE heater on) |
| MECHANICAL |
|
| Color / Material |
Ivory / Plastic + Metal |
| Dimensions (WxHxD) |
Ø223.4 x 293.6mm (Ø8.8" x 11.56") |
| Weight |
3.2Kg (7.05 lb) |
